Wholesale 135° Special Angle Slide-On Hinge

Product Overview

Our 135° corner cabinet hinge is an economical slide-on hardware solution designed specifically for diagonal corner cabinets and angled door transitions. It ensures that cabinet doors align flush against diagonal side panels without leaving gaps, making it a reliable staple for high-volume modular kitchen and wardrobe manufacturing. To see how this model fits into your overall hardware matrix, view our Cabinet Hinge Opening Angles Explained: 90°, 110°, 135°, 165° and 180°.

Key Features

Compatible with Standard Corner Cabinet Geometries

Designed around standard corner cabinet angles used in modular kitchens and furniture production. This cross-compatibility helps distributors and furniture manufacturers streamline inventory planning and simplify sourcing.

Standard 35mm Boring Compatibility

Fits standard 35mm hinge cup boring specifications with an 11.3mm cup depth. It integrates directly into existing automatic drilling lines without requiring machinery re-calibration.

Stable Slide-On Base Plate

The classic slide-on arm structure allows clean, secure alignment during production. Assembly workers simply slide the hinge arm onto the pre-fixed plate and lock it with a single tracking screw.

High-Strength Iron Structure

Stamped from durable cold-rolled steel (iron) to handle the specific cantilever leverage and pulling stress unique to angled door connections, preventing sagging over long-term use.

Application Scenarios

• Diagonal Corner Cabinets: The industry-standard solution for diamond-shaped corner units in kitchen cabinetry and retail displays.

• Angled Door Connections: Perfect for transition wardrobes, custom reception desks, and modular storage units with angled architectural layouts.

• Mass Housing Project Cabinetry: A budget-friendly, high-durability hardware choice for large-scale apartment specifications requiring angled kitchen layouts.

Technical Specifications

Why Import From MINVEE

• Direct Factory Pricing: Ex-factory quotes from our automated production lines, bypassing trading company markups.

• OEM Customization: Custom logo stamping on the hinge body and private-label retail packaging options for bulk distributors.

• Seaworthy Export Packing: Heavy-duty master cartons stacked on wrapped pallets to maximize container space and reduce your unit freight costs.

• Secure Payment Clearance: Reliable trade processing channels to support uninterrupted supply for our international B2B partners.

FAQ

What is the exact difference between a 135° hinge and a 165° hinge?

A 135° hinge is a corner transition hinge used specifically for diagonal/angled cabinet doors so the door closes flush against an angled frame. A 165° hinge is a wide-angle full-access hinge used on standard straight-frame cabinets or fold-out corner units to pull the door completely out of the walkway.

Can this 135° hinge be used with standard 35mm drilling lines?

Yes. It uses the universal 35mm cup diameter and an 11.3mm depth, making it fully compatible with standard automated drilling templates used for traditional 90-degree hinges.

Is this corner hinge available in a hydraulic soft-close version?

This specific model is a highly cost-effective, non-hydraulic mechanical spring version designed for budget-conscious project tenders. We also manufacture a hydraulic soft-close variation; please contact our sales desk for specifications.
